CWWK 1U Firewall Hardware B150 Core i3 7100, 4 x 10Gb SFP+ LAN Firewall Appliance VPN Router PC, RAM SSD OPNsense Hardware 19”Rackmount for Homelab with VGA, SIM
Technical Specifications
Detailed technical information and specifications for this product
Processor
Intel Core i3-7100 / i5-7500 / i7-7700
Memory
Up to 64GB DDR4
Storage
1 × mSATA SSD + 3 × SATA 3.0
Networking
8 × 2.5GbE LAN + 4 × 10GbE SFP+
Expansion
1 × mini-PCIe
I/O Ports
RJ45 Console, USB 3.0, VGA, LAN
Form Factor
19" 1U Rackmount
Operating System
Windows, pfSense, OPNsense, OpenWrt, Linux, PVE, ESXi
Processor
| CPU Model | Core i3-7100（2 Cores / 4 Threads）/ Core i5-7500（4 Cores / 4 Threads）/ Core i7-7700（4 Cores / 8 Threads） |
| Cores / Threads | Core i3-7100（2 Cores / 4 Threads）/ Core i5-7500（4 Cores / 4 Threads）/ Core i7-7700（4 Cores / 8 Threads） |
| Base / Turbo Frequency | Core i3-7100（3.9GHz / No Turbo）/ Core i5-7500（3.4GHz / 3.8GHz）/ Core i7-7700（3.6GHz / 4.2GHz） |
| Cache | Core i3-7100（3MB Intel Smart Cache）/ Core i5-7500（6MB Intel Smart Cache）/ Core i7-7700（8MB Intel Smart Cache） |
| TDP | Core i3-7100（51W）/ Core i5-7500（65W）/ Core i7-7700（65W） |
Memory
| Memory Type | DDR4 SO-DIMM |
| Memory Slots | 2 × SO-DIMM slots |
| Maximum Capacity | Up to 64GB |
| Memory Speed | DDR4 3200MHz |
| Dual Channel | Supported |
Storage
| M.2 Slots | 1 × mSATA SSD slot |
| SATA Support | 3 × SATA 3.0 |
| Included Cable | SATA cable included |
Networking
| Ethernet | 8 × Intel i226-V 2.5GbE RJ45 LAN |
| SFP+ Ports | 4 × Intel X710 10GbE SFP+ |
| Wi-Fi | Optional via mini-PCIe |
| Bluetooth | Optional via mini-PCIe |
| Bypass Function | Optional customization |
Expansion & I/O
| Expansion Slot | 1 × PCIe 4.0 x16 (supports full-height GPU) |
| USB Ports/USB Pin Header | 2 × USB 3.0/2 × USB 2.0 pin header |
| GPIO | 1 × 8-channel programmable GPIO |
| Power Supply | AC 100–240V, 50–60Hz |
Need Dual Power Supply?
This 1U rackmount firewall computer comes with a single PSU by default. For redundant dual power supply configuration, please add an additional PSU separately.
